Chassis: TA-02 SW (short wheelbase), FRP double deck configuration
Drive: Four wheel shaft drive, dogbone

Motor: Torque-Tuned 540 size brushed
Motor Mount: Aluminum
Rear Differential: Ball type
Spur Gear: 74 tooth plastic
Pinion Gear: 21 tooth metal
Suspension: Fully independent double wishbone
Shocks: CVA plastic body oil-filled
Tires: Slick rubber 2.5" (64mm) diameter, front width 1.02" (26mm),
rear width 1.2" (31mm), with foam inserts
Wheels: Two piece plastic, with chrome and copper colored finish,
front width 1.02" (26mm), 1.25" (32mm) rear width, 1.9" (48mm)
diameter
Steering: Bellcrank type
Ball Bearings: Full set included
Body: Polycarbonate
Camber: Non-adjustable, camber refers to the angle of the tops of the
tires from vertical when viewed from front or behind vehicle
Caster: Adjustable front only, caster/toe-in refers to the angle of
the front suspension when viewed from the side of the car in
relation to the chassis

TT-02 Porsche 934 Jagermeister with Brushed Motor, Body, Tires,
Wheels, Foam Inserts, Decals, Shock Oil, Instruction Manual

Radio: 2-ch with steering servo
Battery: 7.2V stick pack with standard connector
Battery Charger: For selected batery pack
Polycarbonate safe spray or brush-on paint
Track and maintenance equipment

Vehicle-
Length: 17.1" (435mm)
Width: 7.9" (202mm)
Height: 5.1" (130mm)
Wheelbase: 9.3" (236mm)
Body-
Length: 17" (432mm)
Width: 6.4" (164mm) narrowest point, 7.9" (200mm) at rear wheels,
widest point
Height: 3.8" (98mm)
