AXI AX90047 SCX10 II Jeep Cherokee RTR 4x4
The 1/10 SCX10 II 2000 Jeep Cherokee is the ultimate mix of exceptional engineering and superior scale realism. It’s fully loaded and packed with innovative features, such as a revolutionary AR44 Hi-Pinion axle for added ground clearance and better drives
- Brand:
- AXI
- Availability:
- In stock
- Delivery time:
- 3-4 Days
$409.99
Excl. tax
The next generation of SCX10 is here!
The 1/10 SCX10 II 2000 Jeep Cherokee is the ultimate mix of exceptional engineering and superior scale realism. It’s fully loaded and packed with innovative features, such as a revolutionary AR44 Hi-Pinion axle for added ground clearance and better driveshift angles, as well as a 3-gear AX10 transmission and a chassis-mounted steering servo. Other highlights include a water-resistant 35T motor, a waterproof, LiPo-compatible AE-5 ESC and a Tactic TTX300 3-channel SLT radio system.
- Officially licensed 1/10 scale 2000 Jeep® Cherokee body with molded scale detail parts.
- Water-resistant 35T brushed motor.
- Waterproof, 3S LiPo-compatible AE-5 ESC with laser-etched heat sink and Star® Plug.
- Tactic™ TTX300 3-channel SLT™ radio with TR325 3-channel SLT receiver and water-resistant Tactic TSX45 metal gear servo, with torque rated at 151 oz.-in.
- 1.9" BF Goodrich T/A® KO2 tires for dependability on rough back-roads.
- Durable black 1.9" Method Mesh wheels for a clean line look.
- JCR Classic Rock Sliders and Vanguard Bumpers.
- Dual slipper clutch design uses a pad on each side of the spur gear for added surface area, allowing more precise tuning and holding power.
- Weight is forward-biased for improved handling.
- Full-time 4WD locked drivetrain.
- Ultra-compact, adjustable AX10™ three-gear transmission.
- Chassis-mounted servo (CMS).
- First-in-class AR44 Hi-Pinion axle with 8¡ kingpin angle and up to 45° of steering.
- Waterproof receiver box is located on the side plates for easy access and low-CG.
- Front/rear WB8 HD Wildboar™ driveshafts feature an updated design with a larger diameter cross pin for added strength.
- Steel C-channel side rails.
- Adjustable body mounting system.
- Improved suspension geometry.
The original AX10 axle was developed in 2007 for Axial's first kit, the AX90001 Axial AX10 Scorpion RC Comp 10 - 1/10th Scale Rock Crawler - Electric Kit. In 2008, the AX10 axle was used in the SCX10 chassis, which paved the way for the scale trail scene.After seven years of utilizing the original AX10 axle and two years of development, Axial is proud to introduce the industry’s first high pinion gear set in our newly developed AR44 axle! The next chapter of the Axial SCX10 begins with true technological engineering and scale realism!
AR44 HI-PINION AXLES
In 2008, the AX10ª axle was used in the launch of the SCX10™ chassis platform. After seven years of utilizing the original AX10™ axle and two years of development, Axial is proud to introduce the newly developed AR44 axle with the industry's first high pinion gear set. The next chapter of the Axial SCX10™ begins with scale realism backed with true technological development!- High pinion gears for added ground clearance & better driveshaft angles
- The high pinion design allows increased gear surface contact for increased durability
- Larger load bearings used around the gear set to reduce flex and create a stronger drivetrain
- Single piece axle housing for added strength
- 1-piece all-metal locker front and rear
- Small pumpkin for increased clearance and a more realistic, scale look
- Bolt on link mounts
- Knuckle carriers and straight axle adapters have a better mounting system with 10-degree increment adjustments
- Optimized gear ratio Ð 3.75 compared to 2.92 previously. This reduces torque twist which is typically seen with other small pumpkin axle designs
KINGPIN ANGLE
- 8 degree kingpin angle
- Improved scrub radius over the AX10 axle
AR44 UNIVERSAL AXLE SET
Universal joint axles allow up to 45 degrees of steering and provide smoother action for a higher performing, efficient drivetrain.
35T BRUSHED MOTOR, WATER RESISTANT
Providing an even balance of speed and crawling, the 35-turn brushed motor features a worry-free design with an integrated cooling fan allowing for extended periods of use. Easy operation: no tuning, no fuel, and no loud exhaust noise. Just plug 'n' go!
AX10™ TRANSMISSION
The ultra compact transmission allows for a wide range of gearing choices. The overall ratio can be adjusted using different pinion and spur gear choices allowing super high speed or competition level crawling speed.
ALL STEEL SUSPENSION LINKS
Strong steel links for both suspension and steering. Large M4 rod ends for durability.
CHASSIS MOUNTED SERVO (CMS)
- Scale looks with proper suspension geometry
- Anodized aluminum links included w/ M4 rod ends
- Adjustable servo mounting system allows for a wide range of servos to be used
- Properly designed suspension for nearly zero bump steer
WB8 HD WILDBOAR™ DRIVESHAFTS
- 3-piece driveshaft with strengthened slider-floater tube
- Increased surface at the connection between the ball joints and output shaft tubes
- 2x11mm cross pin adds 25% more surface area providing more strength for the ball joint
- Captured cross pin design eliminates older set screw design for more durability/easy maintenance
- Adjustable length driveline parts included in box
1.9 BFGOODRICH ALL-TERRAIN T/A® KO2 TIRES - S30
- Officially licensed by BFGoodrich
- 4.65" x 1.65" / 1.9 (118mm x 42.5mm)
- S30 compound
1.9 METHOD MESH WHEELS
The 'less is more' approach is quite refreshing and the mesh wheel offers just that. Clean, simple and METHOD STRONG! These officially licensed METHOD Mesh Wheels are replicated in true form for durability and a clean line look.STEEL C-CHANNEL FRAME RAIL CHASSIS
The realistic high strength c-channel chassis frame is made of durable steel with cross bracing for reinforcement and is held together with all hex hardware. Realistic looking frame and cross braces improve chassis rigidity (torsional stiffness). Realistic shock hoops with multiple shock mounting positions allows you to adjust your suspension for maximum performance. The simplified design makes maintenance and assembly quick and easy. The contoured skid plate significantly reduces hang-ups on terrain. Compared to the previous design, additional holes have been added to the rear portion of the frame rails for making wheelbase adjustments.ADJUSTABLE WHEELBASE
- Wheelbase adjustment is easily done in the rear end without affecting the steering geometry and maintaining zero bump steer.
- Adjustable wheelbase (11.4"/ 12.0" / 12.3") with optional links sold separately
- 4 link rear
- 12.3" wheelbase
JCR OFFROAD VANGUARD BUMPERS AND XJ ROCK SLIDERS
Scale front and rear bumpers and rock sliders licensed by JCR Offroad.- Rear mount has been extended and stiffer plastics chosen to help limit the typical sag seen in plastic bumpers
- Lenses included for light locations on bumpers
- Rear tow hitch included for added scale appearance
- Rock sliders specifically sized to fit the Axial Jeep® Cherokee body and the design allows for adjustable widths
2000 JEEP® CHEROKEE BODY
Pre-painted body with molded scale detail parts (Grill with clear lenses, mirrors, door handles and liftgate trim panel).
RECEIVER BOX, WATERPROOF
Three different silicone seals are included, one for the antenna, one for the servo wires (includes three slots for three channels), and one that acts as a gasket for the receiver box cover. No more stress when running in mud, water, or snow!WIRE ROUTING
Wire routing has been thoroughly thought through to help keep your chassis layout looking clean. In addition to including wire clips/guides, there has been a channel created that runs the length of the chassis so you can run additional wires hidden inside the c-channel frame.
DUAL SLIPPER CLUTCH
Our dual slipper design uses a pad on each side of the spur gear for added surface area. This allows for more precise tuning and holding power. The spur gear features strong, 32 pitch gearing for high torque applications.
ADJUSTABLE COILOVER SHOCKS
The threaded shock bodies hold a single coilover spring. They are oil filled and allow you to tune the dampening rate.
TACTIC TTX300 3-CHANNEL SLT RADIO
Sport-level racers and bashers will appreciate the Tactic TTX300’s many popular features, along with its amazing adjustability. It features a programmable 3rd channel making for incredible versatility; it can operate functions such as two-speed shifting, winches and lights, making it ideal for a vast array of opportunities. Need more reasons? There’s SLT (Secure Link Technology), which creates an unbreakable link between the receiver and your transmitter with push-button ease.
TACTIC 3-CHANNEL 2.4GHz RECEIVER
The Tactic TR325 2.4GHz receiver uses no crystals and features an internal antenna, so you’ll experience worry free driving without frequency conflicts or antenna damage. This lightweight, compact, and bind button equipped receiver with LED indicator makes setup easy!
AE-5 ESC, WATERPROOF
- Male Star Plug lead - compatible with the most common polarized plug.
- Jumper 1 provides a simple plug and play choice between LiPo or NiMh.
- Jumper 2 switches Drag Brake settings.
- Waterproof design with Star Plug / laser etched heat sink.
